Display and control
The current operational status of the Highway Lane Change Assist function is clearly displayed on the instrument cluster of your Kia EV2. For more comprehensive information regarding interface icons, refer to the LCD display modes section.
The real-time status of Highway Lane Change Assist on the Kia EV2 digital display cluster is presented according to the following layout:
|
|
Highway Lane Change Assist system indicator
Green (
): System is ready
Green (
) blinking: System is actively operating
Gray (
): System is in standby mode
White (
) blinking: System has been cancelled (displays temporarily after cancellation occurs)
Lane line
The highlighted lane line graphics match the exact color code of the Highway Lane Change Assist indicator (1). However, complete lane detection availability continues to be shown even while the system rests in Standby.
Green arrow and directional shading
The visual green directional arrow materializes after a specified duration elapses following the initiation of the maneuver, remaining visible until the lane change sequence successfully concludes.
System message notifications
An informative message appears if Highway Lane Change Assist is temporarily restricted when you engage the turn signal lever.
A notification message pops up whenever Highway Lane Change Assist experiences unexpected cancellation during an active maneuver.
To turn Highway Lane Change Assist ON, use the dedicated Driving Assist or Lane Driving Assist button on your steering wheel.
When an interactive prompt asking whether you wish to utilize Highway Lane Change Assist appears on the cluster screen of your Kia EV2, simply press the OK button.
Turning ON Highway Lane Change Assist
|
|
Highway Lane Change Assist is fully ready to execute maneuvers when the feature is turned ON and all of the following prerequisite conditions are completely satisfied:
Highway Driving Assist is currently active and operating normally.
Lane Following Assist is actively engaged and operating.
Your Kia EV2 vehicle is powered ON and has successfully detected surrounding traffic more than once.
Your current vehicle speed exceeds 30 km/h (20 mph).
The system operates only when a vehicle in the rear blind spot is detected at low speeds (Europe: 30–80 km/h (20–40 mph); Australia: 30–60 km/h) and when no active collision risk is determined during the lane change trajectory.
The instrument cluster does not display any active hands-off warnings.
Your vehicle hazard warning lights are switched OFF.
TIP
Whilst the Lane Change Assist function remains ON, Lane Following Assist will not cancel, even if you temporarily operate the turn signal indicator or hazard flashers.
Lane Change Assist automatically turns OFF when you drive under certain conditions:
There is only 1 available driving lane.
Approaching road segments featuring an upcoming intersection or crosswalk.
Roadways lacking physical center separation structures, such as solid guardrails or concrete medians.
A pedestrian or cyclist is detected directly on the road ahead.
When the driving speed drops to 25 km/h (15 mph) or below while the system is in an operable state, it automatically switches to standby.
At low speeds (Europe: 30–80 km/h (20–40 mph); Australia: 30–60 km/h), the system shifts to standby if vehicles in the rear blind spots of both left and right adjacent lanes are not detected.
If any potential collision risk is calculated, the system immediately switches to standby.
The Lane Change Assist status reverts to standby if a risk of collision is identified.
The exact graphical icons or color schemes may vary slightly depending on your specific instrument cluster specifications or theme configuration.
The rendered lanes and surrounding objects visible in the digital cluster may occasionally differ from actual physical road conditions.
WARNING
When Highway Lane Change Assist turns OFF, Steering Assist is temporarily suspended. Always exercise heightened caution while driving your Kia EV2.
Highway Lane Change Assist operation
|
Highway Lane Change Assist executes its maneuver when the function status is ready, you push the turn signal lever to position (1) or (2), and all underlying conditions are satisfied:
Your hands maintain a firm grasp on the steering wheel.
The intended lane change direction presents no calculated risk of collision.
You are driving on a multi-lane road featuring broken lane markings of any color in the desired direction of travel.
There are no active Forward Collision-Avoidance Assist or Blind Spot Collision-Avoidance Assist warning alerts.
Your vehicle is positioned near the center of the lane rather than hugging either side.
The road infrastructure where you are driving or initiating the lane change meets all technical operation requirements for Highway Lane Change Assist.
TIP
When you push the turn signal lever to position (1), Highway Lane Change Assist initiates. If you subsequently return the turn signal lever to the neutral position before crossing the lane line, the assistant cancels.
Highway Lane Change Assist does not cancel after your vehicle crosses the lane line, but the function automatically concludes and the turn signal turns OFF once the lane change maneuver is fully completed.
When you push the turn signal lever to position (2) and hold it for a designated duration, the green directional arrow appears. Highway Lane Change Assist will still proceed even if you release the turn signal lever back to its resting neutral position.
While you are actively changing lanes, the turn signal indicator continues to blink automatically even if you release the stalk. The indicator turns OFF as soon as the lane change finishes.
Highway Lane Change Assist standby
Highway Lane Change Assist enters a standby state whenever any of its ready-state conditions become unfulfilled or when navigating specific challenging road layouts:
Main highway thoroughfares situated within close proximity to a toll plaza gate
Road dead ends lacking a connecting interchange or junction
Sharply curving roadway segments
Road stretches featuring unusually narrow driving lanes
Cancelling Highway Lane Change Assist
Highway Lane Change Assist cancels automatically under the following driver inputs:
You push the turn signal lever in the opposite direction of the active lane change.
You apply excessive manual steering input or turn the wheel too sharply.
You activate the turn signal lever to position (1) while Lane Change Assist is operating, then return the lever to neutral before the vehicle crosses the lane boundary.
WARNING
Highway Lane Change Assist is forcefully cancelled under any of these circumstances:
You turn Highway Driving Assist OFF.
You turn OFF or temporarily cancel Lane Following Assist or Smart Cruise Control.
The instrument cluster triggers a hands-off warning message.
You switch the vehicle hazard warning lights ON.
The instrument cluster displays a Forward Collision-Avoidance Assist or Blind-Spot Collision-Avoidance Assist warning alert.
Your Kia EV2 detects a potential collision risk in an adjacent lane, even in the absence of explicit FCA or BCA warnings.
The targeted destination lane comes to an end.
Your vehicle sensors lose detection of the target lane markings.
An electrical or mechanical fault affects the turn signal lights.
The function becomes OFF because it was disabled via the settings menu, the roadway transitions to a one-way path, an intersection or crosswalk approaches, a pedestrian or cyclist appears in the path, or you enter a road lacking physical dividers like a median or guardrail.
The driving speed falls to 25 km/h (15 mph) or below while the system is operable, causing it to transition to standby.
At low speeds (Europe: 30–80 km/h (20–40 mph); Australia: 30–60 km/h), if valid vehicles are not detected within the rear blind spots of adjacent left and right lanes.
A sudden collision risk is determined by vehicle sensors.
The lane along the direction of the intended change is no longer marked by a single dashed line.
Your vehicle detects an immediate risk of collision.
If you manually cancel Highway Lane Change Assist mid-operation, your Kia EV2 may steer back toward the center of the original lane or suspend steering assist entirely depending on real-time dynamics. Always remain vigilant and monitor road conditions.
Highway Lane Change Assist may experience reduced functionality or fail to operate normally on complex urban roads featuring pedestrians or cyclists near intersections and crosswalks.
