Kia EV2: Forward Collision-Avoidance Assist operation / Lane-Change Side function: (if equipped)

The advanced Lane-Change Side functional capabilities integrated into the comprehensive Forward Collision-Avoidance Assist architecture of your Kia EV2 comprise:

• Collision Warning

• Emergency Steering

Collision Warning

1. Collision Warning

Collision Warning can alert you with the emergency steering warning light blinking (), a warning message, an audible warning, and steering wheel vibration. The warning light appears on the outside rearview mirror when a vehicle is detected in the right or left lane from the rear.

Collision Warning may be activated under the following conditions:

• Collision Warning may be activated when your driving speed is approximately 40-145 km/h (25-90 mph).

• It is within a certain period of time after the vehicle is determined to have departed its lane.

• The object enters the operating range of the Lane-Change Side function.

• Driving on a straight lane.

Emergency Steering

Emergency Steering

Emergency Steering can alert you with Emergency Steering warning light blinking (), a warning message, an audible warning, and steering wheel vibration.

The warning light on the outside rearview mirror appears when a vehicle is detected in the right or left lane from the rear. Emergency Steering may activate to avoid a collision.

Emergency Steering may activate under following conditions:

• Emergency Steering activates when your speed is approximately 40-145 km/h (25-90 mph).

• Side-approaching vehicle and motorcycle speed: whilst driving.

• It is within a certain period of time after the vehicle is determined to have departed its lane.

• The object enters the operating range of the Lane-Change Side function during overtaking.

• Driving on a straight lane.

• Both lanes are detected.

• There is no risk of a secondary collision.

CAUTION

• The system does not operate when the side-approaching vehicle or motorcycle is stopped.

• Lane-Change Side function does not operate if the oncoming vehicle is stopped.

• These functions do not work when a car or motorcyclist in the next lane is stationary.

• The front-side and rear-side radar detection range is based on the width of standard roads. On narrow roads, warnings may be triggered by a vehicle or motorcyclist driving in the next lane. Conversely, on wide roads, radars may fail to recognise a vehicle or motorcyclist driving in the next lane.

• The Lane-Change Side function deactivates in the following situations:

  • You drive more than a certain distance into the next lane.

  • You move away from the direction where there is a risk of collision.

  • You turn the steering wheel rapidly.

  • You engage the brake pedal.

  • Forward Collision-Avoidance Assist activates.

• After the Lane-Change Side function is triggered or after you change lanes, be sure to move into the centre of the lane. If you continue to drive along the edge of the lane, the Lane-Change Side function may deactivate.

NOTE

• If an additional accident risk is detected due to Emergency Steering, only a Collision Warning may be issued to notify you of the danger.

• If the driver’s seat is on the left, a collision warning may occur when turning left; if the driver’s seat is on the right, a collision warning may occur when turning right.
